EtherLite®

Network Serial Concentrators

Product is not recommended for new designs.
Multiplexes all serial ports into a single TCP/IP session
Basic, low-cost serial servers
Network serial concentrators with 8, 16 or 32 ports

Overview Part Numbers & Accessories Specifications Resources Product Support

The EtherLite family of network serial concentrators adds serial ports to an Ethernet network, eliminating the installation of serial adapters inside servers. It offers easy installation and network efficiency and control at a low price per port. Available in 8- to 32-port models, the EtherLite can be used in numerous applications including retail/POS, process control, data collection and console management of clusters, routers, hubs, switches, PBXs and other networking devices with console ports.

A single TCP/IP session services the traffic from all ports, unlike the conventional one-session-per-port method. This means less overhead at the host and less traffic on the Ethernet. With Digi’s patented RealPort® drivers, the EtherLite ports appear as local TTY ports under UNIX® and as native COM ports under Microsoft® Windows®. These locally administered ports allow full control of serial ports.

Available in 8- to 32-port models, the EtherLite can be used in numerous applications including retail/POS, process control, data collection and console management of clusters, routers, hubs, switches, PBXs and other networking devices with console ports.

Download datasheet

Add to compare

Product support

Default

Narrow Part Numbers

Cellular Network

Wireless

Wired

	PART NUMBER
EtherLite 160 - 16-port RS-232 RJ-45 terminal server	70001427	HOW TO BUY Contact Us View Accessories
EtherLite 160 - 16-port RS-232 RJ-45 terminal server (International)	70001528	HOW TO BUY Contact Us View Accessories
EtherLite 80 - 8-port RS-232 RJ-45 terminal server	70001767	HOW TO BUY Contact Us View Accessories
EtherLite 80 - 8-port RS-232 RJ-45 terminal server (International)	70001768	HOW TO BUY Contact Us View Accessories
EtherLite 162 - 16-port RS-232/RS-422 RJ-45 terminal server	70001428	HOW TO BUY Contact Us View Accessories
EtherLite 162 - 16-port RS-232/RS-422 RJ-45 terminal server (International)	70001529	HOW TO BUY Contact Us View Accessories
EtherLite 32 - 32-port RS-232 RJ-45 terminal server with rack kit	70001429	HOW TO BUY Contact Us View Accessories
EtherLite 32 - 32-port RS-232 RJ-45 terminal server with rack kit (International)	70001533	HOW TO BUY Contact Us View Accessories

Specifications	EtherLite 80	EtherLite 160, EtherLite 162	EtherLite 32
Features
Management	DHCP
Software	Patented RealPort COM port redirector for COM/TTY ports for Microsoft® Windows®, UNIX® and Linux®
Status LEDs	Link, Power
Dimensions (L x W x D)	11.5 in x 1.2 in x 5.4 in (29.3 cm x 2.9 cm x 13.8 cm)	11.5 in x 1.2 in x 5.4 in (29.3 cm x 2.9 cm x 13.8 cm)	15.1 in x 1.8 in x 7.6 in (38.4 cm x 4.5 cm x 19.2 cm)
Weight	3.1 lb (1.4 kg)	3.1 lb (1.4 kg)	5.8 lb (2.6 kg)
Operating Systems	AIX, HP-UX, Solaris, Linux®, Windows® 2000, Windows® XP, Windows® 7, Windows® 8, Windows® 8.1, Windows® 10, Windows Server® 2003, Win-dows Server® 2008, Windows Server® 2012. Note: TCP/UDP socket services are operating system independent
Other	Multiplexes all serial ports into a single TCP/IP session, minimizing Ethernet traffic; Auto-detection of either 10 Mbps or 100 Mbps Ethernet (EtherLite 80, 160 and 162 models); Field upgradeable; Supports DHCP for easy IP address configuration
Interfaces
Serial
Ports	8 RS-232	16 RS-232 (RS-232/422 switchable model options)	32 RS-232
Connectors	RS-232, RJ-45F with built-in transient voltage suppression
Throughput	Up to 115 Kbps on all ports simulataneously	Up to 115 Kbps on all ports simulataneously	Supports up to 115 Kbps on all ports, but not simulataneously
Signal Support	TXD, RXD, RTS, CTS, DTR, DSR and DCD
Ethernet
Ports	10/100 Mbps 10/100Base T; Full or Half duplex	10/100 Mbps 10/100Base T; Full or Half duplex	10 Mbps 10Base-T; Full or Half duplex
Processor & Memory
CPU	40 MHz 80C186 embedded microcontroller
SRAM	512 K at zero wait states
EPROM	128 K flash at zero wait states
Power Requirements
Power Input	External, 100-240 VAC, 50/60 Hz	External, 100-240 VAC, 50/60 Hz	Internal, 100-240 VAC, 50/60 Hz
Power Consumption	15 W typical, 20 W max	15 W typical, 20 W max	20 W typical, 25 W max
Environmental
Operating Temperature	10° C to 40° C (50° F to 104° F)
Relative Humidity	5% to 90% (non-condensing)
Ethernet Isolation	1500 VAC min per IEEE802.3/ANSI X3.263
Serial Port Protection (ESD)	+15 kV human body model
Approvals
Safety	UL 1950; EN 60950
Emissions/Immunity	FCC Class A; EN55022; Class A or B; EN55024; EN61000-3-2,3; EN50082-1,2
