The Digi Connect Wi-ME 9210 embedded system-on-module (SoM) enables secure wired and wireless networking. Built on Digi's powerful NS9210 ARM9 processor, these high-performance modules allow customers to implement next generation network-enabled products. Additionally, their RJ-45 form factor is pin compatible with other Digi Connect ME and Digi Connect ME 9210 modules.
Read more
| North America: | International: | ||
|
Digi Connect Wi-ME 9210 Digi JumpStart Kit for NET+OS 7
View details |
DC-WME-9210-NET |
Contact Us |
|
|
Digi Connect Wi-ME 9210 Digi JumpStart Kit for Digi Embedded Linux
View details |
DC-WME-9210-LX |
Contact Us |
| Digi JumpStart Kits | North America: | International: | |
| Digi Connect Wi-ME 9210 Digi JumpStart Kit for NET+OS 7 View details |
DC-WME-9210-NET |
Contact Us |
|
| Digi Connect Wi-ME 9210 Digi JumpStart Kit for Digi Embedded Linux View details |
DC-WME-9210-LX |
Contact Us |
|
| Models for NET+OS | North America: | International: | |
| Connect Wi-ME 9210 4/8 NET+OS View details |
DC-WME-Y402-C |
Contact Us |
|
| Connect Wi-ME 9210 4/8 NET+OS (50) View details |
DC-WME-Y402-C-B |
Contact Us |
|
| Connect Wi-ME 9210 8/16 NET+OS View details |
DC-WME-Y413-C |
Contact Us |
|
| Connect Wi-ME 9210 8/16 NET+OS (50) View details |
DC-WME-Y413-C-B |
Contact Us |
|
| Models for Linux | North America: | International: | |
| Connect Wi-ME 9210 8/16 Linux View details |
DC-WME-Y413-LX |
Contact Us |
|
| Connect Wi-ME 9210 8/16 Linux (50) View details |
DC-WME-Y413-LX-B |
Contact Us |
| Specifications | Digi Connect Wi-ME® 9210 | |
| General | ||
| Processor Type | 32-bit Digi NS9210 processor | |
| ARM Core | ARM926EJ-S | |
| Processor Speed | 75 MHz | |
| Cache | 4k I/D Cache | |
| Memory Base Population | Support up to 8 MB NOR Flash Support up to 16 MB SDRAM |
|
| Flexible Interface Modules (FIMs) | 300 MHz DRPIC165X CPU 2k program/192 bytes data RAM |
|
| On-chip 256-bit AES Accelerator | • | |
| Power Management Modes | On-the-fly clock scaling Low-power sleep modes Configurable scaling/wake-up events (EIRQ, UART, Ethernet, etc.) |
|
| Pins/Form Factor | RJ-45 connector style with 20-pin micro pin header (Samtec FTS-110-01-F-DV-TR) | |
| High-Speed TTL Serial Interface | Full signal support (TXD, RXD, RTS, CTS, DTR, DSR and DCD) Hardware/Software flow control |
|
| GPIO | 10 shared Up to 3 external IRQ options |
|
| SPI | Master data rate up to 16.7 Mbps Slave data rate up to 7.5 Mbps |
|
| I2C | v1.0 bus interface 7-bit and 10-bit address modes |
|
| Flexible Interface Support (FIM) | UART, 1-Wire, USB device (low-speed), CAN BUS | |
| Watchdog Timer (16-bit) | • | |
| JTAG Interface | Available on development modules only | |
| On-Board Power Supervisor | • | |
| Wave-Solderable Design | No clean flux process | |
| Dimensions (L x W x H) | 1.445 in (36.7 mm) x 0.75 in (19.05 mm) x 0.735 in (18.67 mm) | |
| Network Interface – Wireless LAN | ||
| Standard | IEEE 802.11 b/g/n | |
| Frequency | 2.4 GHz | |
| Data Rate | Up to 65Mbps with automatic fallback | |
| Modulation | CCK (11/5 Mbps), DQPSK (2 Mbps), DBPSK (1 Mbps), OFDM (6, 9, 12, 18, 24, 48, 54 and 65 Mbps) | |
| Typical Transmit Power | +17dBm | |
| Receive Sensitivity | -69dBm @ 54 Mbps | |
| Connector | 1 x RP-SMA | |
| WLAN Security | ||
| WEP (Wired Equivalent Privacy) | 64/128-bit encrycption (RC4) | |
| WPA/WPA2/802.11i | 128-bit TKIP/CCMP (AES) encryption. Enterprise mode (802.1X): LEAP (WEP only), PEAP, TTLS, TLS, EAP-FAST, GTC, MD5, OTP, PAP, CHAP, MSCHAP, MSCHAPv2, TTLS-MSCHAPv2. Pre-shared key mode (PSK/Personal). |
|
| Environmental | ||
| Operating Temperature | -40° C to +75° C (-40° F to +167° F) -40° C to +85° C (-40° F to +185° F) with external thermal pad* | |
| Storage Temperature | -50° C to +125° C (-58° F to +257° F) | |
| Relative Humidity | 5% to 90% (non-condensing) | |
| Altitude | 12,000 feet (3,658 meters) | |
| Power Requirements (3.3VDC) | ||
| Maximum | 450 mA (1.485 W) | |
| Typical | 346 mA (1.14 W) UART and Ethernet activated |
|
| Idle | 186 mA (613 mW) /16 clock scaling, Ethernet activated |
|
| Sleep | 34 mA (113 mW) Wake-up on EIRQ, Ethernet PHY off |
|
| Regulatory Approvals | ||
| FCC Part 15 Class B, EN 55022 Class B | • | |
| EN 61000-3-2 and EN 61000-3-3 | • | |
| ICES-003 Class B, VCCI Class II, AS 3548 | • | |
| FCC Part 15 Sub C Section 15.247 | • | |
| IC RSS-210 Issue 5 Section 6.2.2(o) | • | |
| EN 300 328, EN 301 489-17 | • | |
| UL 60950-1, EN 60950 (EU) | • | |
| CSA C22.2, No. 60950 | • | |
| EN 55024 | • | |
| Intentional Radiation | • | |
