Digi Connect EZ 4 TS — 4-port RS-232/22/485 software-selectable serial device server

Digi Connect EZ 4 TS

4-port RS-232/22/485 software-selectable serial device server

• Connectors:
  • Ethernet: 10/100/1000 Ethernet
  • Serial Ports (RJ45 10-pin): (4) RJ45-10; RS-232 DTE/RS-422/RS-485 capable, software selectable
  • RS-232 / EIA-232 / Serial Modes: Signal support TXD, RXD, RTS, CTS, DTR, DSR, DCD, RI flow control options: XON/OFF, CTS/RTS, RTS-toggle
  • RS-422 / EIA-422 Serial Modes: TX+/−, RX+/−, software termination, pre-delay/ post-delay
  • RS-485 / EIA-485 Serial Modes: TX+/−, RX+/−, software termination, pre-delay/ post-delay
  • Console (RJ45 10-pin): RS-232 console serial port
• Physical:
  • ​Dimensions (L x W x H): 132.08 × 83.82 × 22.86 mm (5.2 × 3.3 × 0.9 in)
  • Package dimensions: 210.82 × 182.88 × 63.5 mm (8.3 × 7.2 × 2.5 in)
  • Weight: 0.75 kg (1.65 lb)
  • Status LEDs: System: Power; Per port: Ethernet, Serial, Console
• Power requirements:
  • ​Power Input: 9 – 30 VDC at 0.8 A max
  • Power Supply: 12 VDC power supply with locking barrel connector included
• Environmental:
  • ​Operating temperature:
    • Standard operating temperature: 0 °C to 40 °C (32 °F to 104 °F)
  • Storage temperature:
    • Standard storage temperature: 0 °C to 60 °C (32 °F to 140 °F)
  • Relative humidity: 5% to 95% (non-condensing)
• Approvals:*
  • Safety: IEC 62368-1, CB, UL 62368-1
  • Emissions / Immunity: CE, FCC Part 15 Class A, ICES-003, AS/NZS CISPR 22, EN 55035, EN 55032
• Product warranty: 5-year for base Connect EZ TS device
• Technical support: 1-year Digi LifeCycle Assurance ;includes: 24×7 expert support and centralized device management via Digi Remote Manager (cloud) or Digi On-Prem Manager (local)
• Software and management:
  • Remote management: Digi Remote Manager or Digi On-Prem Manager, SNMP v3 (user installed, managed)
  • Local management: Digi On-Prem Manager and Digi Navigator discovery and configuration tool, Web UI (HTTP/HTTPS); CLI (Telnet, SSH)
  • Management / troubleshooting tools: Digi Navigator discovery and configuration tool, FTP client, SCP, protocol analyzer with PCAP for Wireshark, event logging with syslog and SMTP client, NTP/SNTP, Nagios, Intelliflow, iPerf, Dynamic DNS, ping, traceroute
  • Memory: 256 MB RAM, 4 GB Flash
  • Authentication: TACACS+, LDAP, Enterprise RADIUS
• Accessories: not included; power supply — 12 V, 1.5 A, locking barrel, includes NA, EU, UK, AU and barrel to bare wire adapter (76000823) and AC power cord (US: 760000769, EU: 76000772) available separately

What's in the box

• Digi Connect EZ 4 TS  — 4-port RS-232/22/485 software-selectable serial device server
