CONNECTIONS |
SFP+ |
(2) 10 Gb capable SFP+ sockets |
✓ |
✓ |
✓ |
✓ |
ETHERNET |
(2) 10/100/1000 Ethernet |
✓ |
✓ |
✓ |
✓ |
SERIAL PORTS (RJ45 10-pin) |
RS-232 |
16 |
|
32 |
|
RS-232/422/485 capable, software selectable |
|
16 |
|
32 |
RS-232 / EIA-232 SERIAL MODES |
Signal support TXD, RXD, RTS, CTS, DTR, DSR, DCD, RI flow control options: XON/OFF, CTS/RTS, RTS-toggle |
✓ |
✓ |
✓ |
✓ |
RS-422 / EIA-422 SERIAL MODES |
TX+/-, RX+/-, software termination, pre-delay/post-delay |
|
✓ |
|
✓ |
RS-485 / EIA-485 SERIAL MODES |
Data+/Data-, software termination, pre-delay/post-delay |
|
✓ |
|
✓ |
CONSOLE (RJ45 10-pin) |
RS-232 serial console port |
✓ |
✓ |
✓ |
✓ |
USB |
(2) USB 3.1 Gen 1 (Type A) |
✓ |
✓ |
✓ |
✓ |
MICRO XSD |
SD/SDHC/SDXC socket |
✓ |
✓ |
✓ |
✓ |
CELLULAR (WHEN USED WITH DIGI CORE PLUG-IN LTE MODEM) |
CORE MODULE SUPPORT |
Digi CORE module compliant socket (see accessories for modules) |
✓ |
✓ |
✓ |
✓ |
CERTIFICATIONS |
Visit product certifications for latest certifications |
When used with Digi CORE plug-in LTE modem |
LTE (G4) WITH DIGI CORE PLUG-IN LTE MODEM 1002-CMG4 |
LTE Cat 4: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B38, B40, B41; 3G: B1, B2, B4, B5, B6, B8, B19; |
2G EDGE / GPRS: 850 / 900 / 1800 / 1900 MHz |
CONNECTORS |
(1) 50 Ω SMA (center pin: female) |
SIM SLOTS |
(2) Mini-SIM (2FF) |
SIM SECURITY |
Secured in cellular module |
PHYSICAL |
DIMENSIONS (L x W x H) |
25.5 cm x 44.5 cm x 4.445 cm (10.4 in x 17.5 in x 1.75 in) |
PACKAGE DIMENSIONS |
37.5 cm x 57.5 cm x 15.24 cm (14.76 in x 22.64 in x 6 in)
Ships with attachable 19” rack ears |
PACKAGE WEIGHT |
|
5.2 kg (11.5 lb) |
5.26 kg (11.6 lb) |
STATUS LEDs |
System: Power 1, Power 2, Fan 1, Fan 2, Sys Fan, User, WWAN Signal, WW Service
Per port: Ethernet, Serial, Console, USB |
POWER REQUIREMENTS |
POWER INPUT |
AC: Single or dual AC input (C13 connector), use with appropriate National Mains cords
DC: Dual DC power with EZ16-AD00, with supplied Phoenix connectors |
POWER CONSUMPTION |
AC: Single or dual field replaceable, 100 – 240 VAC, ~50 – 60 Hz, 2.4 A max for each power supply
DC: Dual field replaceable, 48 VDC, 2.9 A max for each power supply |
REPLACEABLE POWER SUPPLY |
Product supports redundant replaceable power supplies |
ENVIRONMENTAL |
OPERATING TEMPERATURE |
Standard operating temperature: 0 °C to 50 °C (32 °F to 122 °F) |
STORAGE TEMPERATURE |
Standard storage temperature: 0 °C to 70 °C (32 °F to 158 °F) |
RELATIVE HUMIDITY |
5% to 95% (non-condensing) |
APPROVALS* |
SAFETY |
IEC 62368-1, IEC 60950-1, CB, EN 62311, UL 62368-1, UL 60950-1 |
EMISSIONS / IMMUNITY |
CE; RED; FCC Part 15, Subpart B; ICES-003; AU/NZS; CISPR 32, CISPR 35 |
WARRANTY AND SUPPORT |
PRODUCT WARRANTY |
5-year for base Connect EZ device, 3-year for Digi CORE plug-in LTE modem |
TECHNICAL SUPPORT |
1-year LifeCycle Assurance with 24x7 Expert Support included |
SOFTWARE AND MANAGEMENT |
REMOTE MANAGEMENT |
Digi Remote Manager®; SNMP v3 (user installed/managed) |
LOCAL MANAGEMENT |
Digi Navigator™ discovery and configuration tool, Web UI (HTTP/HTTPS), CLI (Telnet, SSH) |
MANAGEMENT / TROUBLESHOOTING TOOLS |
Digi Navigator discovery and configuration tool, FTP client, SCP, protocol analyzer with PCAP for Wireshark, event logging with syslog and SMTP client, NTP/SNTP, Nagios, Intelliflow, iPerf, Dynamic DNS, ping, traceroute |
MEMORY |
256 MB RAM, 4 GB Flash |
AUTHENTICATION |
TACACS+, LDAP, Enterprise RADIUS |
