| CONNECTIONS |
| SFP+ |
10 Gb capable SFP+ sockets |
|
2 |
2 |
2 |
| ETHERNET |
10/100/1000 Ethernet |
2 |
2 |
2 |
6 |
| SERIAL PORTS (RJ45 10-pin) |
RS-232 serial ports |
8 |
8 |
|
8 |
| RS-232/422/485 (MEI) serial ports |
|
|
8 |
|
| RS-232 / EIA-232 SERIAL MODES |
Signal support TXD, RXD, RTS, CTS, DTR, DSR, DCD, RI flow control options: XON/OFF, CTS/RTS, RTS-toggle |
✓ |
✓ |
✓ |
✓ |
| RS-422 / EIA-422 SERIAL MODES |
TX+/-, RX+/-, software termination |
|
|
✓ |
|
| RS-485 / EIA-485 SERIAL MODES |
Data+/Data-, software termination |
|
|
✓ |
|
| CONSOLE (RJ45 10-pin) |
RS-232 serial console port |
✓ |
✓ |
✓ |
✓ |
| USB |
USB 3.1 Gen 1 (Type A) |
2 |
2 |
2 |
2 |
| DIGITAL / ANALOG |
Digital IO / analog input |
|
|
|
2 / 1 |
| MICRO SD |
SD/SDHC/SDXC socket |
✓ |
✓ |
✓ |
✓ |
| WI-FI |
| MODULE |
1 x 1 SISO secure dual-band 802.11a/b/g/n/ac (2.4 GHz / 5 GHz) |
|
✓ |
|
|
| MODES |
Client mode and access point mode simultaneously |
|
✓ |
|
|
| CLIENTS |
Maximum 10 clients (access point mode: regardless of combination of clients and access points) |
|
✓ |
|
|
| ACCESS POINTS |
Maximum 2 access points (access point mode: regardless of combination of clients and access points) |
|
✓ |
|
|
| SECURITY |
WPA-3/WPA-2 personal, WPA/WPA-2 enterprise |
|
✓ |
|
|
| CONNECTORS |
(1) 50 Ω SMA (center pin: male) |
|
✓ |
|
|
| CELLULAR (WHEN USED WITH DIGI CORE PLUG-IN LTE MODEM) |
| CORE MODULE SUPPORT |
Digi CORE module compliant socket (see accessories for modules) |
| CERTIFICATIONS |
Visit product certifications for latest certifications |
| LTE (G4) WITH DIGI CORE PLUG-IN LTE MODEM 1002-CMG4-GLB |
LTE Cat 4: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B38, B40, B41; 3G: B1, B2, B4, B5, B6, B8, B19; |
| 2G EDGE / GPRS: 850 / 900 / 1800 / 1900 MHz |
| CONNECTORS |
(2) 50 Ω SMA (center pin: female) |
| SIM SLOTS |
(2) Mini-SIM (2FF) |
| SIM SECURITY |
Secured in cellular module |
| PHYSICAL |
| DIMENSIONS (L x W x H) |
26 cm x 16 cm x 4.445 cm (10.25 in x 6.5 in x 1.75 in) |
| PACKAGE DIMENSIONS |
35 cm x 28.5 cm x 15.5 cm (13.75 in x 11.25 in x 6.12 in)
Ships with attachable 19” rack ears |
| PACKAGE WEIGHT |
3.22 kg (7.1 lb) |
| STATUS LEDs |
System: Power, WWAN Signal, WWAN Service, Wi-Fi
Per port: Ethernet, Serial, Console, USB |
| POWER REQUIREMENTS |
| POWER INPUT |
Supplied with 100 to 240 V AC external power supply or can be used with direct 12 V DC power;
Power input connector is Phoenix connector, included with power supply |
| POWER CONSUMPTION |
12 V DC at 5 A max (100 to 240 V AC external power supply included) |
| ENVIRONMENTAL |
| OPERATING TEMPERATURE |
Standard operating temperature: 0 °C to 50 °C (32 °F to 122 °F) |
| STORAGE TEMPERATURE |
Standard storage temperature: 0 °C to 70 °C (32 °F to 158 °F) |
| RELATIVE HUMIDITY |
5% to 95% (non-condensing) |
| APPROVALS |
| SAFETY |
IEC 62368-1, IEC 60950-1, CB, EN 62311, UL 62368-1, UL 60950-1 |
| EMISSIONS / IMMUNITY |
CE; RED; FCC Part 15, Subpart B; ICES-003; AS/NZS; CISPR 32, CISPR 35 |
| TAA |
| TAA COMPLIANCE |
This product is compliant with the U.S. Trade Agreements Act (TAA) based on its current country of origin and manufacturing configuration. Compliance status is subject to change. Customers should contact Digi International to obtain the latest TAA Compliance Statement. |
| WARRANTY AND SUPPORT |
| PRODUCT WARRANTY |
5-year for base Connect EZ device, 3-year for Digi CORE plug-in LTE modem |
| LIFECYCLE ASSURANCE |
1-year LifeCycle Assurance includes: 24×7 expert support and centralized device management via Digi Remote Manager (cloud) or Digi On-Prem Manager (local) |
| SOFTWARE AND MANAGEMENT |
| REMOTE MANAGEMENT |
Digi Remote Manager; SNMP v3 (user installed/managed) |
| LOCAL MANAGEMENT |
Digi On-Prem Manager; Digi Navigator discovery and configuration tool, Web UI (HTTP/HTTPS), CLI (SSH) |
| MANAGEMENT / TROUBLESHOOTING TOOLS |
Digi Navigator discovery and configuration tool, FTP client, SCP, protocol analyzer with PCAP for Wireshark, event logging with syslog and SMTP client, NTP/SNTP, Nagios, Intelliflow, iPerf, Dynamic DNS, ping, traceroute |
| MEMORY |
2 GB RAM, 8 GB flash |
| AUTHENTICATION |
TACACS+, LDAP, Enterprise RADIUS |
